(3 Bay) Compliant Modular Building

Product DetailsThe compliant modular is a high specification modular system that is designed to rival traditional buildings, with long design life and high specification that can be easily designed to meet building and energy regulations.The module structure is built from a hot rolled steel ring beam incorporating galvanised steel floor joists, steel corner columns and steel lattice roof beams, with a clear design span of up to 12m or 40ft.On the roof a 15mm tongue and grooved timber decking is usually fitted with a fatra ecopro PVC fire rated membrane, soffit roof construction and plastic uPVC rain water goods.Walls are constructed with timber wall studs typically clad in plastisol coated steel exterior finish. Wall insulation is provided by ecobrite foil therm together with 90mm fibreglass insulation. Internal finish to wall and ceiling with typically 12.5mm or 15mm plasterboard interior finish with UPVC architraves.COMPLIANT MODULAR BUILDING Benefits5Kn per metre square floor loading0.75Kn per metre square roof loadingChoice of Mono pitched or dual pitched roofEnd to end and side by side linkingChoice of 2.4m, 2.7m or 3m ceiling heightsChoice of vinyl floor covering, carpet tiles or non slip surfacesStandard UPVC windows with powder coated aluminium optionsStandard steel multi-point locking doors or UPVC or powder coated steelOption to upgrade U values depending on local regulationTypical UsesHead officesSatellite officesSports clubhousesCanteen and meeting facilitiesTraining roomsThe price quoted is for a 3-bay open plan 32ft x 30ft compliant modular building and includes supply and delivery of the building. Final on-site installation and cranage into position is not included. Larger sizes, customisation and options available at additional cost.Product SpecificationsExternal Length (m)9.62External Width (m)9.02External Height (m)3.4Internal Length (m)9.38Internal Width (m)8.78Internal Height (m)2.4Door Width (m)0.81Door Height (m)2.0Compliant Modular BuildingCompliant Modular Buildingelitecontainers
